Details: With this full kit set can set up the company, or authority of office building image standardization management, improve the management level, at the same time, standardized internal management system. Specifications: Working voltage: DC 12V Unlock current: ?1000mA Static current: ?60mA Memory: 250 standard users Card read distance: 0-10 cm RF type: EM card Working temperature: -10 ~ 70 C Wide rel. humdity range : 10 to 90 % Door open options (admin user selectable): Card (Key Tag) & Password/ Card (Key Tag) Only/ Password Only Item dimension: 11.7*11.7*2.1cm Power supply: This AC110V--240V Power supply controller is a transformer which provides stable output voltage for access controller, lock, and exit button. Can reduce the load of access controller, save wiring to reduce the hidden trouble Set NC / NO outputs, can control various types of electric locks Based delay control circuit, lock time can be in 0-15 seconds The circuit board has remote control port. Specification: Input Voltage: AC 110~220V 50~60Hz Output Voltage: DC 12V 3A Electric lock Parameters: Fail Safe:unlock when power off Lock body size: 200Lx34Wx42H(mm) Face plate size:200Lx34Wx3H(mm) Blot out plate size: 210Lx42Wx0.8H(mm) Magnet bracket:90Lx24Wx3H(mm) Lock pin: 15.5mmDIA,stainless steel out throw15mm Voltage: DC12V Start Current: 0.8A; Standby Current: 0.09A Solid lock pin: polishing housing, 800Kg Holding Force Suitable For: wood door, metal door, glass door Exit Button: Maximun Power Rating: 36 VDC 3A-5A output Support both NC Mode (Fail Safe Mode) & NO Mode (Fail Secure Mode) Performance Testing: 1000000 times aging test. Material: Hard Plastic Here are 5pcs 125KHz RFID Proximity ID cards and 5 key fobs, they can work with the product which has 125Khz RFID card reader. Package Includes: 1 x Access control keypad 1 x Electric Bolt lock 1 x Power supply 1 x Exit button 5 x Id card 5 x Keyfob 1x Remote Control 1x Doorbell
Package Dimensions: 5.9 x 3.9 x 3.9 inches
