Realtime T304f Plus Face With Fingerprint Attendance With Access Control
Realtime T304f Plus Face With Fingerprint Attendance With Access Control
Couldn't load pickup availability
"Realtime T304f Plus Face With Fingerprint Attendance With Access Control" is a sophisticated solution designed to streamline attendance management and access control. Utilizing facial recognition and fingerprint technology, it ensures accurate and secure attendance tracking. With an intuitive interface and advanced features, it optimizes workforce management and enhances security. The T304F Plus Face also integrates access control capabilities, offering a comprehensive solution for maintaining controlled environments. Its advanced features, robust performance, and user-friendly design make it an ideal choice for various industries and organizations seeking efficient attendance and access management.
SPECIFICATIONS
| Face Capacity | 1000 |
| Fingerprint Capacity | 1000 |
| Card Capacity | 1000 |
| Password Capacity | 1000 |
| Max Attendance Log | 100,000 |
| Management log | 10000 |
| Identify mode | Face, Card, Password and Combinations |
| Display | 3" LCD |
| Communication | TCP/IP, Wifi Both together |
| Card Reader Connectivity | Yes (Wiegand IN) |
| User Validity | Yes |
| Push Button Connectivity | Yes |
| QR Reader Connectivity | Yes (Wiegand IN) |
| U-disk | Supported |
| Battery | Built-In Battery Backup |
| Working voltage | DC12V |
| Working temperature | -10°c~ +50°c |
| Working humidity(RH) | 20% ~ 80% |
| Self-test function | Supported |
| Access Control | Built In |
Download Brochure :- https://realtimebiometrics.com/catalogue/1907220219_doneT304f+.pdf
Realtime T304F+
Specifications
Realtime T304F+ is a face and fingerprint attendance terminal with card and password options and built-in access control. It suits offices that want Wi-Fi and LAN together, a battery backup and the option of a slave reader. It stores 1,000 faces and 1,000 fingerprints.
| Face capacity | 1,000 |
|---|---|
| Fingerprint capacity | 1,000 |
| Card capacity | 1,000 |
| Password capacity | 1,000 |
| Attendance records | 1,00,000 |
| Management log | 10,000 |
| Fingerprint verification | 1:1, 1:N |
| Working modes | Offline and online |
| Verification modes | Face, fingerprint, ID card, password and combinations |
| Screen | 3 inch colour display |
| Communication | Wi-Fi, Ethernet (TCP/IP), USB disk |
| Power supply | 12 V DC |
| Working current | 500 mA |
| Sound indicator | Buzzer, voice |
| QR reader support | Yes, on Wiegand IN |
| Card reader connectivity | Yes, on Wiegand IN |
| Wiegand | IN and OUT |
| Exit button support | Push button and no-touch button |
| User validity | Yes |
| Battery | Built-in battery backup |
| Working temperature | -10 °C to +50 °C |
| Working humidity | 20% to 80% RH |
| Self-test function | Supported |
| Access control | Built in |
Specifications checked against Realtime's published details for this model. All prices include GST.
Frequently asked questions
How many users can the T304F+ store?
It stores 1,000 faces, 1,000 fingerprints, 1,000 cards and 1,000 passwords, with up to 1,00,000 attendance records.
Can it use Wi-Fi and LAN at the same time?
Yes. The listing states TCP/IP and Wi-Fi work together, and USB disk is also supported.
Can the T304F+ open a door lock?
Yes. Access control is built in, and it supports a push exit button or a no-touch exit button.
Can I add a slave reader on the exit side?
Yes. Realtime lists the T304F+ as a supported master for its RS 9+ and SFR7 slave readers.
Can I connect a QR or card reader?
Yes. QR readers and external card readers connect on the Wiegand IN port.
Can I set an expiry date for a user?
Yes. The user validity feature lets you limit how long a user can punch or enter.
Does it work in a power cut?
Yes, it has a built-in battery backup.
What power supply does it need?
It works on 12 V DC and draws about 500 mA.
How is it different from the T304F Mini?
The T304F+ stores 1,000 faces against 500 on the Mini. Both have a 3 inch screen and 1,000 fingerprint capacity.
How does a biometric attendance machine work?
It identifies each person by fingerprint, face, palm or card and records the exact punch time. Reports can be downloaded as Excel or PDF, and many models connect to software over LAN or Wi-Fi, depending on the model.
Can the same machine also open a door?
Many models have a relay output that can control an electronic door lock, so one device can mark attendance and give door access. Check the product specifications for the relay or access control feature.
What do I need to install it?
A wall mount or desk stand, a power adapter and, for network models, a LAN cable or Wi-Fi. Our team gives free technical support for setup.
