BioMax
Speed Face 5 Visible Light Facial Attendence and Access Control
Speed Face 5 Visible Light Facial Attendence and Access Control
Couldn't load pickup availability
AI Face Recognition Terminal
SpeedFace 5 is the face recognition product with high performance and high reliability, which depends on the deep learning algorithm, also having the characteristicsof quick recognition speed and high accuracy. This product supports 1:1 and 1:N mode, with embedded card reader.
Functions
Face Capacity : 50,000
Card Capacity : 50,000
Max User : 50,000
Logs Capacity : 2,00,000
Living body detection : Support
Stranger detection : Support
Recognition distance configuration : Support
Remote upgrade : Support
Deployment : Public network, LAN
Display
Display screen : 5-inch IPS all-sight LCD touch screen
Resolution : 854 * 480
System parameters
Operating system : Linux
CPU : Dual-core ARM Cortex
Interfaces
Serial communication interface : 1-way RS-232
Relay output : 1-way door-opening signal output
Wiegand out : Yes
Signal input 2 ways, 1-way door magnetic signal input, 1-way door button input
Network interface : 1-way 100M Ethernet
Reset interface : 1 Reset button
Card Option : Mifare
USB interface : 1-way Type-A
Audio output : Not support
Video output : Not support
Speaker : 1 built-in speaker
Alarm interface : 2-way alarm input
Tamper button : 1
Heat module : Not support
General parameters
Protection grade : IP54
Power : DC 12V/2A
Working temperature : -10°C~50°C
Storage temperature : -20°C~60°C
Working humidity : 10%~90%
Dimension : 190.00 * 87.53 * 17.00 mm
